Microfocus Digital PCB X Ray Inspection Machine 20 FPS PCB Inspection Equipment

Basic Information
Place of Origin: China
Brand Name: SOCHI
Certification: ISO
Model Number: RYT-3000
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Standard wooden case or according to customers' requirement
Delivery Time: in stocks or within 23 working days
Payment Terms: T/T, Western Union,Paypel
Supply Ability: 10 Set/Sets per Month
Detail Information
Model No.:: RYT-3000 Light Tube Type:: Enclosed X-ray Tube
Maximum Tube Voltage:: 90kV Maximum Tube Current:: 0.15mA
Speed:: 20 Fps Resolution:: 1176*1104
Size Of Loading:: 650mm*550mm(other Sizes Can Be Customized )
High Light:

pcb x ray inspection equipment

,

pcb x ray machine


Product Description

Microfocus Digital PCB X Ray Inspection Machine 20 FPS PCB Inspection Equipment

1.Application:



1. Semiconductor

2. Electronic Connector Module

3. Automotive electronics

4. Mold Plastic Parts

5. Aircraft Components

6. Electrical and Mechanical Components

7. BGA Inspection

8. PCB,FPC,PCBA

9. Die Castings





2.Main Function:



Function Advantages
X-ray tube and detector can move along the Z axis Defects below 2um can be detected
Software sets voltage and current Convenient maintenance, long service life

It can control the speed of the object carrier in the X-Y direction



Simple operation and short training time for operators
Editable detection program Suitable for mass detection
The maximum inclination of detector is 45° Semi-automatic identification of OK/NG products
Large navigation window, click the mouse to move the object table to the point High repeatability accuracy
Can accommodate all kinds of large size samples
Allows a unique view of the sample



3.Technical Parameters:



Project   Content
Equipment Model No.   RYT-3000

X-RAY transmitting tube

(HAMAMATSU,Japan)

Light tube type Enclosed X-ray tube
Maximum tube voltage 90kV
Maximum tube current 0.15mA
The focal spot size 5um
Amplification factor Geometric multiplier: 150 system multiplier: 1000
Detector Speed 20 fps
Resolution 1176*1104
Angle of inclination ±45° incline
Cabinet Specification Size of loading platform 650mm*550mm(other sizes can be customized )



4.Standard Configuration:



Item Name
QTY
Unit
Remark
90KV-5um Enclosed X-ray
tube
1 PCS
Objective table
1 PCS
Size:650mm*550mm
Flat Panel Detector
1 PCS
High definition
Image Processor CPU
1 PCS
Multiple functions
LCD(liquid crystal display)
1 PCS
24''





5.Our Service:

A, 24 hours technical support by email and telephone service..
B, Warranty: 1year for free repair (Except consumables), provide free technical service support for all life.
C, Provide English manual or operating video.

6.More picture:

Microfocus Digital PCB X Ray Inspection Machine 20 FPS PCB Inspection Equipment 0Microfocus Digital PCB X Ray Inspection Machine 20 FPS PCB Inspection Equipment 1Microfocus Digital PCB X Ray Inspection Machine 20 FPS PCB Inspection Equipment 2







Contact Details
Sophia Chan

Phone Number : +86-19962795553

WhatsApp : +8619962795553
