| Place of Origin: | China |
|---|---|
| Brand Name: | ISOCHI |
| Certification: | ISO |
| Model Number: | ISC418 |
| Minimum Order Quantity: | 1 set |
| Price: | Negotiation |
| Packaging Details: | Standard wooden case or according to customers' requirement |
| Delivery Time: | 30 days |
| Payment Terms: | T/T, , L/C |
| Supply Ability: | 4 Sets per Month |
| Model No.:: | ISC418 | Machine Dimension:: | 3300*2000*2000mm |
|---|---|---|---|
| X,Y,Z-axis Stroke:: | 560mm*700mm*40mm | Temperature:: | 22±2℃/45%-65% |
| Power Supply:: | 3PH-AC380V+PE,50/60HZ 15KVA | Noise:: | ≤75dBA |
| Air Pressure:: | 6.5-7.5bar | Broken Tool Detection:: | Laser Tool Detector |
| Machine Weight:: | 8000kg | X,Y-axis Measurement System:: | Imported Closed Linear Scale |
| High Light: | pcb drilling equipment,high precision drilling machine |
||
Product Datas:
| X,Y,Z-axis Stroke | 560mm*700mm*40mm |
| X,Y-axis Drive | Imported High-power servo motor(Guaranteed transmission speed) |
| Z-axis Drive | Imported servo motor |
| Max. Working Area | 560mm*700mm*4 |
| Drilling Diameter | Φ0.2mm-Φ6.35mm |
| Spindle Speed | 160-180krpm ABL/Westwind(Optional) |
| Max. Drilling speed | 480-550hole/min |
| Spindle cooling method | Water cooling |
| Tool Change Mode | Antomatic Tool Change |
| Machine Dimension | 3300*2000*2000mm |
| Spindle Spacing | 560mm |
Notes:
The drilling speed depends on the thickness of the plate, the number of plates and the hole size. The drills on the 2*1.6mm PCB,for 0.3 holes the drilling speed is more than 460 holes/min； 0.5 holes,and the drilling speed is more than 510holes/min.
Working Conditions:
| Power Supply: | 3PH-AC380V+PE,50/60HZ 15KVA |
| Temperature: | 22±2℃/45%-65% |
| Noise: | ≤75dBA |
| Air Pressure: | 6.5-7.5bar |
